「ボディーバランスしかり、サウンド、プリアンプの利き方・・・現場主義、即戦力とはこのことではないでしょうか？是非、この『生アクティブベース』XJ-1Tに触れてみて下さい！」
高橋佳輝


高橋佳輝くんホームページ
http://www.yoshikitakahashi.com/


XOTiC Guitar
XJ-1T/24F/BGM/Alder/R



Body :
Alder
Color :
Burgundy Mist
Neck :
24F Maple/Rosewood
Neck Finish :
Oil Finish
Nut :
Pure Bone
Fret :
Jescar Silver Nickel(#6150 type)
Pick up :
XOTiC JB-5st
Tuner :
HipShot Ultra Light
Bridge :
HipShot 5 string A Brass Chrome
Control :
1Vol, 1Balancer, 1Tone, 3-Blond EQ Tri-logic 2 Bass Preamp
(Mid/Bright SW,Output Gain Control)
Switch :
Pull Volume for Passive/Active
Hardware :
Chrome
Strap Button :
Gotoh
Strings :
D'Addario
Neck Scale :
34inch
Weight :
4.5kg 〜 4.6kg(9.92 lbs to 10.14 lbs)
Nut Width :
46.9mm(1.848 inch)
Neck Width at The Last Fret :
73.9mm (2.913 inch)
String Spacing at The BRIDGE :
19.0mm (0.748 inch)
Price :
340,000円 [357,000円] 税込
Tri-logic 2 Bass Preamp :
Three Band EQ (high, mid, low) boost & cut. Center position produces flat,unaltered sound, with no added tonal coloration.



* Mini Toggle Switch - Use the Switch closer to the headstock to switch the mid-frequencies (400Hz/800Hz), and the other Switch to switch the treble-frequencies (6Hz/12kHz).
* Pre-set gain control to boost gain by one to three times (located in back panel for easy access).
* 18V drive is for more headroom, which allows incoming signals to pass through cleanly, without clipping the high-end or low-end frequencies.
(Requires two 9V batteries)

Tri-logic 2 Bass Preamp Frequency Specification

SW1 (MidSwitch):Off/On-@400Hz/800Hz ー ±12dB
SW2 (BrightSwitch):Off/On-@6KHz/12K ー ±18dB
